CONN RCPT FMALE 114P GOLD SOLDER | LEMO
114 Position Circular Connector Receptacle, Female Sockets Solder
Images may differ
Unit Price ($ / pc.)
156.31 $
*
Available: 328 pcs.
Next delivery: 5838 pcs.
Available in 2 Weeks
Manufacturer Leadtime: 18 Weeks **
Quantity
Price per unit*
100 pcs.
148.4945 $
500 pcs.
140.679 $
1000 pcs.
132.8635 $
3000 pcs.
125.048 $
10000 pcs.
117.2325 $
*incl. VAT plus
shipping costs
**Subject to prior sale
Description
The HEW.5M.114.XLNP is a common industry Circular Connector Assemblies housed in a RoHS compliant Standar package by LEMO made. The HEW.5M.114.XLNP is using SPQ 1 pieces and MSL1 packing size. Buy new and original item from Innovo Technology distributor, contact by email: sales@hk-innovo.com
Technical specifications
| Mfr | LEMO |
| Series | 5M |
| Package | Bulk |
| Product Status | Active |
| Connector Type | Receptacle, Female Sockets |
| Number of Positions | 114 |
| Shell Size - Insert | 114 |
| Shell Size, MIL | - |
| Mounting Type | Panel Mount, Through Hole |
| Mounting Feature | Bulkhead - Front Side Nut |
| Termination | Solder |
| Fastening Type | Threaded |
| Orientation | W |
| Primary Material | Metal |
| Shell Material | Aluminum Alloy |
| Shell Finish | Nickel |
| Contact Finish - Mating | Gold |
| Color | Gray |
| Ingress Protection | IP68 - Dust Tight, Waterproof |
| Material Flammability Rating | - |
| Features | Potted |
| Shielding | Shielded |
| Current Rating (Amps) | 2A |
| Voltage Rating | - |
| Cable Opening | - |
| Operating Temperature | -20°C ~ 80°C |
| Backshell Material, Plating | - |
| Contact Material | Bronze |
| Contact Finish Thickness - Mating | 59.0μin (1.50μm) |
| Insert Material | Polyetheretherketone (PEEK) |
| Applications | Aerospace, Automotive, Aviation, Military |
| Base Product Number | HEW.5M |
Download
Logistics
| Country of origin | HK |
| Customs tariff number | - |
| Original Packaging | Reel with 1 pieces |
Compliance
| RoHS conform | Yes |
| HTSUS | 8504.40.9580 |
| SVHC free | Yes |
