FERRITE CORE 3.77UH N97 | EPCOS - TDK Electronics
Uncoated N97 Ferrite Core Type 0.787 (20.00mm) Length 0.551 (14.00mm) Width Diameter 0.091 (2.30mm) Height
Images may differ
Unit Price ($ / pc.)
1.1562 $
*
Available: 164 pcs.
Next delivery: 2394 pcs.
Available in 1 Weeks
Manufacturer Leadtime: 11 Weeks **
Quantity
Price per unit*
100 pcs.
1.09839 $
500 pcs.
1.04058 $
1000 pcs.
0.98277 $
3000 pcs.
0.92496 $
10000 pcs.
0.86715 $
*incl. VAT plus
shipping costs
**Subject to prior sale
Description
The B66483K0000X197 is a common industry Ferrite Cores housed in a RoHS compliant Standar package by EPCOS - TDK Electronics made. The B66483K0000X197 is using SPQ 1200 pieces and MSL1 packing size. Buy new and original item from Innovo Technology distributor, contact by email: sales@hk-innovo.com
Technical specifications
| Mfr | EPCOS - TDK Electronics |
| Series | I20/2.3/14 |
| Package | Box |
| Product Status | Active |
| Supplier Device Package | I 20 x 2.3 x 14 |
| Material | N97 |
| Diameter | - |
| Inductance Factor (Al) | 3.77 μH |
| Tolerance | ±25% |
| Gap | Ungapped |
| Effective Permeability (μe) | 1260 |
| Core Factor (ΣI/A) mm1 | 0.42 |
| Effective Length (le) mm | 25.1 |
| Effective Area (Ae) mm2 | 59.8 |
| Minimum Core Cross Section (Amin) mm2 | 55 |
| Effective Magnetic Volume (Ve) mm3 | 1500 |
| Finish | Uncoated |
| Height | 0.091 (2.30mm) |
| Length | 0.787 (20.00mm) |
| Width | 0.551 (14.00mm) |
Download
Logistics
| Country of origin | HK |
| Customs tariff number | - |
| Original Packaging | Reel with 1200 pieces |
Compliance
| RoHS conform | Yes |
| HTSUS | 8504.40.9580 |
| SVHC free | Yes |
